Measuring medium or Application

Liquid,gas or steam etc.

Operation mode

It can be measured liquid level and pressure.

Gauge pressure, absolute pressure, sealing pressure

Installation mode

bottom or bottom side of water tank.

Display mode

Can be selected display type and without display type.

Range

-0.06bar-0-1bar to 0-100bar

Power supply

24VDC

Accuracy

0.075%F.S,0.1%F.S,0.25%F.S

Output signal

4～20mA、Hart protocol

Working Temp.

-25～80℃，-25～200 to 500℃ etc.high temperature can be customized

Environmental Temp.

-20～80℃

Diaphragm material

316L SUS, Hastelloy C,tantalum,Monel,PTFE on the diaphragm.

Process connection

Welded pipe joint、Threaded connection、Flange connection.

Protection grade

IP65

weight

2.9kg
